4 wire ignition switch diagram
4 wire ignition switch diagram





The voltage spike on the secondary coil becomes greater since it has more turns of the coil. So, when the switch is turned on, a change in the magnetic field occurs. The induced voltage is not enough to create a spark. The 12 volts battery powers up the primary coil on the spark plug, and then the primary coil induces a voltage on the secondary coil (still on the spark plug). When the current supply is cut off (switched off), the magnetic fields collapse into the wire. The magnetic field increases progressively as the current flows rapidly through the coil until it reaches a stable state. The magnetic flux stores charge which can be converted back to electricity.

4 wire ignition switch diagram

The electrical current flows through a conductor such as a coil and creates magnetic flux (or magnetic field) around it (the coil). The ignition coils use the relationship between electricity and magnetism to produce very high voltages. The primary goal of the ignition coil is to generate sufficient voltage required to create a spark. We will now learn how an ignition works in the ignition system of automobiles. Types of Ignitions and Their Wiring DiagramsĬonventional Breaker-points Ignition Systems There is no moisture accumulation – no distributors.There are no moving parts to wear out through friction – the system is electronic.The rotor and the distributor cap are not available.The advantages of a distributor-less ignition system are as follows: They may have either one coil per cylinder or for each pair of cylinders. It is an electronic system.Ī distributor-less ignition system has the ignition module and the engine computer, which controls the spark plug timing. The coils sit right on top of the spark plugs, and there are no spark wires. This is the newest type of ignition system and it is different from both the conventional and electronic ignition systems.

4 wire ignition switch diagram

When the coil has collapsed, the module timing will turn on the current to repeat the cycle. The armature creates a voltage that signals the module to turn on and off. The armature revolves past the sensor to turn the primary current on and off. The entire circuit of the electronic ignition system resembles the conventional one. They have their breaker points replaced with a pickup coil (sensor), and an electronic ignition control module.

4 wire ignition switch diagram

The electronic ignition systems have reduced emissions, higher mileage, and greater reliability. The difference is in the components of the systems, and it is slight. The wiring of an electronic ignition system is similar to that of the conventional system. Additionally, you can check the polarity of your spark plug output to verify if it is positive or negative using a diode rated at 20kV – or any other ideal rating.







4 wire ignition switch diagram
